# Automatic Horizontal Aluminium Coil Packing Line: A Comprehensive Guide
Aluminium coils are widely used in the manufacturing and construction industry. These coils come in different shapes and sizes and need to be transported and stored carefully to prevent damage. This is where the Automatic Horizontal Aluminium Coil Packing Line comes into play. This packing line is specifically designed to pick, pack, and stack slit steel, copper, and aluminium coils, making transportation and storage very convenient. In this article, we will explore the Automatic Horizontal Aluminium Coil Packing Line in detail, discussing its features, specifications, and applications.
## Introduction
The Automatic Horizontal Aluminium Coil Packing Line is a specially designed packing line that is used for packing and transporting aluminium coils. This packing line is capable of packing, stacking, and moving slit steel coils, copper coils, and aluminium coils. The machine is composed of various components that work together to ensure the safe and efficient packing and transportation of coils.
## Machine Application
The Automatic Horizontal Aluminium Coil Packing Line uses compound paper as the main packing material. It is used for coil picking, auto packing, stacking, and more. It makes the object well packed and stacked, convenient for storage and transportation. This packing line can handle a wide range of coil sizes, making it a versatile addition to any manufacturing or construction facility.
## Basic Composition
The Automatic Horizontal Aluminium Coil Packing Line is composed of several components that work together to ensure efficient and effective packing and transportation. These include:
### Turnstile
The turnstile is used to position the coils correctly on the packing line. It helps ensure that the coils are fed into the machine in the correct orientation, increasing efficiency and reducing errors.
### Coil Picking and Tilting System
The coil picking and tilting system is used to pick and tilt the coils correctly. It ensures that the coils are fed into the packing line at the correct angle, reducing the risk of damage.
### Net/Gross Weighing Station
The net/gross weighing station is used to measure the weight of the coils accurately. It ensures that the coils are packed according to their weight range, reducing the risk of damage during transportation.
### PP Tape Strapping
The PP tape strapping component is used to ensure that the coils remain tightly packed during transportation. It prevents the coils from moving or shifting, reducing the risk of damage.
### Wrapping Machine
The wrapping machine is used to wrap the coils tightly, ensuring that they are packed securely. It uses compound paper or LLDPE stretch film to wrap the coils, which helps protect them during transportation.
### Stacking System
The stacking system is used to stack the wrapped coils correctly. It ensures that the coils are stacked neatly, reducing the risk of damage and making transportation more efficient.
### Steel Strapping
The steel strapping component is used to secure the stacked coils. It ensures that the coils remain stacked correctly and that they are not damaged during transportation.
### Electrical Cabinet
The electrical cabinet houses the electrical components of the machine. It ensures that the machine operates correctly and reduces the risk of damage or malfunction.
## Scope of Application
The Automatic Horizontal Aluminium Coil Packing Line can handle a wide range of coil sizes and shapes. Its specifications include:
– OD: 800mm-1500mm
– ID: 508\610mm
– Width: 20mm-300mm
– Weight: ≤2T
– Wrapping Material: LLDPE Stretch Film/Compound Paper
– Wrapping Overlap: 30%-80% adjustable
– Wrapping Material Size: film roll width 90mm, roll OD 500mm, roll ID 76mm
## Conclusion
The Automatic Horizontal Aluminium Coil Packing Line is a versatile and efficient machine that is essential to the manufacturing and construction industry. It ensures that coils are packed and transported safely, reducing the risk of damage and increasing efficiency. Its various components work together to ensure that the coils are packed and stacked correctly, making transportation and storage more efficient. If you are in the market for an automatic coil packing line, the Automatic Horizontal Aluminium Coil Packing Line is an excellent choice.
